Airex PM16162 Pleated Air Filter Merv 10 16x16x2

Product Description

The AIREX PM16162 is a MERV 10 pleated air filter measuring 16 inches x 16 inches x 2 inches, designed for forced-air HVAC systems in residential, commercial, and industrial applications. The filter media is a 100% hydrophobic synthetic polyolefin manufactured by Kimberly-Clark, electrostatically charged to attract and hold airborne contaminants. Efficiency is rated at 65-70% at the 5-10 micron particle range. Initial resistance for the 2-inch depth is 0.26 inches water gauge at 500 feet per minute face velocity. The rigid frame is constructed of heavy-duty moisture-resistant beverage board with integrated support members bonded to each pleat on both sides, preventing pleat collapse and air bypass.

This filter is suited for a wide range of forced-air system installations including rooftop units, air handlers, and residential furnaces and fan coil units. The electrostatically charged hydrophobic media captures dust, pollen, mold spores, and other common airborne particulates at MERV 10 efficiency without requiring power. It is installed by HVAC technicians and facility maintenance professionals in both new construction and retrofit scenarios where indoor air quality improvement or LEED compliance is a priority.

Key Features

• MERV 10 efficiency rating: 65-70% capture at 5-10 micron particle size
• 100% hydrophobic Kimberly-Clark polyolefin media with electrostatic charge for enhanced particulate capture
• Heavy-duty moisture-resistant beverage board frame with integrated pleat support members bonded to both sides of each pleat
• Filter pack bonded to frame interior perimeter, eliminating air bypass
• Heavy expanded wire media support grid with 93% or greater open area, bonded to media to prevent oscillation and pull-away
• UL 900 listed, flammability Class 2 (UL 217V)
• Earns LEED points and supports reduced energy cost through extended filter life-cycle

Compatibility

Designed as an OEM-style replacement or upgrade pleated filter for residential, commercial, and industrial forced-air HVAC systems accepting a 16 x 16 x 2 inch filter. Available in 1-inch, 2-inch, and 4-inch depths; special sizes available upon request.

Installation Notes

This filter is installed by licensed HVAC technicians or qualified maintenance personnel. Power down or switch the system to off at the thermostat and disconnect before servicing the filter compartment. Confirm airflow direction arrow on the filter frame aligns with system airflow before securing. Follow local mechanical codes and manufacturer service intervals for filter replacement schedules.

Technical Specifications

• MERV Rating: 10
• Filter Efficiency: 65-70% at 5-10 micron
• Initial Resistance: 0.26 inches water gauge at 500 FPM
• Nominal Dimensions: 16 inches x 16 inches x 2 inches
• Filter Depth: 2 inches
• Media Material: Kimberly-Clark Hydrophobic Polyolefin (synthetic, electrostatically charged)
• Frame Material: Moisture-resistant beverage board
• Media Support: Heavy expanded wire grid, 93% minimum open area
• Flammability Listing: UL 900 Class 2 (UL 217V)
• Available Depths: 1 inch, 2 inches, 4 inches

Standard Information

• Brand: AIREX
• Manufacturer Part Number: PM16162
