Airex pm14202 Pleated Air Filter 14x20x2 Merv 10

Product Description

The AIREX pm14202 is a 14 x 20 x 2 inch MERV 10 pleated air filter designed for residential, commercial, and industrial HVAC applications. The filter media is a 100% hydrophobic, electrostatically charged synthetic polyolefin engineered to attract and hold airborne contaminants, achieving 65-70% efficiency in the 5-10 micron particle range. The enclosing frame is constructed from a rigid, heavy-duty moisture-resistant beverage board with integrated support members bonded to each pleat on both sides for consistent pleat spacing and structural stability. The filter pack is bonded to the inside frame perimeter to eliminate air bypass. A heavy expanded wire media support grid with at least 93% open area is bonded directly to the media to prevent oscillation and pull-away.

This filter is suited for a broad range of HVAC system installations including residential forced-air systems, light commercial air handlers, and industrial ventilation units. It is commonly installed by HVAC technicians as a standard filter replacement during routine maintenance or system servicing. The MERV 10 rating makes it appropriate for environments where improved indoor air quality and reduced airborne particulate load are priorities. Initial resistance for the 2 inch depth is 0.26 inches W.G. at 500 FPM, keeping system static pressure impact minimal across typical airflow conditions.

Key Features

• MERV 10 rated for 65-70% efficiency at 5-10 micron particle size
• 100% hydrophobic, electrostatically charged synthetic polyolefin media (Kimberly-Clark)
• Rigid moisture-resistant beverage board frame resists deformation in humid conditions
• Pleat support members bonded on both sides to maintain pleat spacing and stability
• Filter pack perimeter bonded to frame to prevent air bypass
• Heavy expanded wire support grid with 93% or greater open area prevents media oscillation
• UL 900 listed, flammability class 2 (UL 217V approval)
• Qualifies for LEED points in applicable building projects

Compatibility

Designed as an OEM-style replacement pleated filter for residential, commercial, and industrial HVAC air handlers and forced-air systems requiring a 14 x 20 x 2 inch filter with MERV 10 performance. Special sizes are available upon request from the manufacturer.

Installation Notes

Installation is performed by HVAC technicians or qualified service personnel. Always power down the air handling unit before removing the existing filter or installing a new one. Verify that airflow direction arrows on the filter frame align with the system airflow direction before seating the filter. Inspect the filter housing for gaps or damaged seals that could allow air bypass around the installed filter.

Technical Specifications

• Filter Size: 14 x 20 x 2 inches
• MERV Rating: 10
• Filtration Efficiency: 65-70% at 5-10 micron
• Initial Resistance: 0.26 inches W.G. at 500 FPM
• Media Type: Kimberly-Clark hydrophobic polyolefin, electrostatically charged
• Frame Material: Moisture-resistant beverage board
• Support Grid: Heavy expanded wire, minimum 93% open area
• Available Depths: 1 inch, 2 inches, 4 inches
• Certifications: UL 900 listed, flammability class 2; LEED point eligible

Standard Information

• Brand: AIREX
• Manufacturer Part Number: pm14202
