Product Information
- Electric Damper Actuator
- Type Adjustable, Asymmetrical
- Operation Type Spring Return, NC
- Voltage Rating 24 Volt AC
- Maximum AC Voltage 24 Volt
- Frequency Rating 50/60 Hertz
- Power Rating 20 Volt Amp
- Torque 60 Inch-Pound
- Angle of Rotation 90 to 160 Degree
- Output Signal 2 to 10 Volt DC
- Size 5-1/2 Inch Width x 6-7/16 Inch Depth x 8-3/4 Inch Height
- Shaft Diameter 3/8 Inch (Square)
- Operating Temperature -40 to 150 Deg F (Ambient)
- Application Damper
- Approval UL (Canada and US), CE, EEC (LVD)
- Contact Rating 7.2 Amp at 120 Volt AC/3.6 Amp at 240 Volt AC (Full Load), 43.2 Amp at 120 Volt AC/21.6 Amp at 240 Volt AC (Locked Rotor)
- Timing 30 to 60 Second
- Mounting Type Foot Mount
- Connection Type Quick Connect Terminal
- Includes Dual Ended Shaft Motor
