AGF AGF1000.1 TESTanDRAIN 1000 Bronze Sectional Floor Control Test and Drain Valve 1 in NPT

Product Description

The AGF AGF1000.1 is a bronze sectional floor control test and drain valve designed specifically for wet fire sprinkler systems. This valve is rated for three hundred psi and combines test and drain functions into one unit, minimizing the need for multiple connections and saving space and time. The compact design features a one-handle ball valve for ease of use. It includes a tamper-resistant test orifice and sight glasses for operational efficiency.

• Compact, one-handle ball valve
• UL and ULC listed, certified for multiple fire safety standards
• Made in the USA with reliability and versatility

Product Highlights

Designed for efficiency and ease, the AGF1000.1 meets stringent safety standards and is ideal for fire protection professionals.

Product Information

Standard Information

• Brand: AGF
• Manufacturer: AGF Manufacturing

Technical Specifications

• Model: 1000
• Material: Bronze
• Pressure Rating: 300 psi
• Ball Material: Chrome-Plated Brass
• Seat Material: Impregnated Teflon
• Stem Material: Rod Brass
• Size: 1 in
• Connection Type: NPT
• Dimension: 5 inches 1/16 length x 6 inches 3/8 height
• Applications: For wet fire sprinkler systems
• Standards/Certifications: UL and ULC listed, NYC-BSA No. 720-87-SM, NFPA-13, NFPA-13R, NFPA-13D, FM approved
