Advance REB4P32SC35M Electronic Fluorescent Ballast 32W T8 Lamp

Product Description

The Advance REB4P32SC35M is an electronic fluorescent ballast designed for T8 lamps with a wattage of thirty-two watts. Operating at one hundred twenty volts, this ballast provides a steady power supply to support up to four lamps efficiently. It is known for its instant start capability and a ballast factor of zero point eight-one, making it suitable for residential applications.

• Designed for four T8 lamps with a total wattage of thirty-two watts
• Features instant start and operates at one hundred twenty volts
• Offers a ballast factor of zero point eight-one for efficient lighting

Product Highlights

This ballast supports residential lighting needs and meets certifications including UL, ISO, FCC, and RoHS standards.

Product Information

Standard Information

• Brand: Advance
• Manufacturer: Advance Transformer

Technical Specifications

• Amperage Rating: 1.57 A
• Dimensions: 9.5 inches L x 1.7 inches W x 1.18 inches H
• Frequency Rating: 60 Hz
• Material: Metal
• Number of Lamps: 4
• Power Factor: 0.6
• Temperature Range: 70 degrees C
• Total Harmonic Distortion: 125%
• Wattage: 103 W
• Lamp Type: T8
• Lamp Wattage: 32 W
• Voltage Rating: 120 VAC
• Start Type: Instant
• Ballast Factor: 0.81
