Advance Products And Systems IL600C Il-600c Innerlynx Mech Seal

Product Description

The ADVANCE PRODUCTS AND SYSTEMS IL600C Innerlynx Mech Seal offers a faster pipe sealing method than caulk, grout, or mastic. These modular mechanical seals are used to easily seal the annular space between the carrier pipe and the ID of a wall penetration. Designed to absorb vibrations, shocks, and sound waves and act as a sound dampener while electrically isolating the carrier pipe.

• Faster pipe sealing method
• Modular Mechanical Seals
• Absorbs vibrations, shocks and sound waves

Product Highlights

The Innerlynx standard modular mechanical seal features a EPDM seal element, composite pressure plates, and is C/US UL Listed.

Product Information

Standard Information

• Brand: ADVANCE PRODUCTS AND SYSTEMS
• Manufacturer Part Number: IL600C
• Country of Origin: USA

Technical Specifications

• Series/Model: Model C
• Sealing Element Thickness: 3.2 IN
• Sealing Element Width: 4.08 IN
• Chord Length: 6.06 IN
• Pressure Plate Size: 6.12 IN Length X 3.07 IN Width X 1.9 IN Depth
• Bolt Size: 3/4 X 8 IN
• Wall Thickness: 8-1/4 IN
• Sealing Range: 3.2 IN Untightened X 4 IN Tightened
• Pipe Size: 12.13 - 118.11 IN
• Material: EPDM Seal Element, Composite Pressure Plates
• Finish/Color: Black Seal
• Industry Standards: C/US UL Listed
• Temperature Rating: -40 To 250 DEG F
• Sub Brand: Innerlynx
• Item Name: Modular Mechanical Seal
• Type: Standard
