Advance IOPA4P32LWN35I 120-277V Ballast Ele

Product Description

The Advance IOPA4P32LWN35I is a fluorescent ballast designed for use in various lighting applications. This ballast operates at input voltages of 120 to 277 volts AC and supports four lamps, each with a wattage of thirty-two. Key features include an automatic restart function and low wattage starting capability, making it efficient and reliable.

• Input voltage range from one hundred twenty to two hundred seventy-seven volts AC
• Supports four F32T8 lamps with a total wattage of one hundred twenty-eight
• UL, CSA approved for safety and reliability

Product Highlights

This ballast is suitable for high-performance fluorescent lighting installations. It features a low starting wattage and a high power factor of 0.98, ensuring energy efficiency.

Product Information

Standard Information

• Manufacturer: Advance
• UPC: 78108711526

Technical Specifications

• Input Current: 0.81 Amp
• Input Power: 94 to 96 Watt
• Frequency Rating: 50/60 Hertz
• Maximum THD: 10 Percent
• Minimum Starting Temperature: -20 degrees Fahrenheit
• Size: 9.5 inches (length) x 1.3 inches (width) x 1 inch (height)
• Maximum Case Temperature Rating: 70 degrees Celsius
• Housing Material: Metal
