Advance IOP4P32N35I OPTANIUM Electronic Fluorescent Ballast 32 W 4 Lamps

Product Description

The ADVANCE IOP4P32N35I OPTANIUM electronic fluorescent ballast is designed for T8 lamps and 32 W lamp wattage. Operates on 120 to 277 VAC and 50/60 Hz frequency. Features instant/rapid start and NEMA 22 enclosure. Constructed with metal and measures 9.5 in L x 1.3 in W x 1 in H.

• Reliable and energy efficient Philips Advance Centium commercial grade specifications, plus added benefits of lamp striation reduction technology
• High power factor
• Suitable for outdoor applications

Product Highlights

This electronic ballast is ideal for T8 lamps, providing reliable and energy-efficient performance with a high power factor and robust construction.

Product Information

Standard Information

• Brand: ADVANCE
• Manufacturer Part Number: IOP4P32N35I
• Country of Origin: MEX

Technical Specifications

• Amperage Rating: 0.4 to 0.95 A
• Enclosure Type: NEMA 22
• Frequency Rating: 50/60 Hz
• Material: Metal
• Minimum Starting Temperature: -20 deg F
• Number of Lamps: 4
• Power Factor: 0.98
• Thermal Protection: Class P
• Total Harmonic Distortion: 10 %
• Lamp Type: T8
• Lamp Wattage: 32 W
• Voltage Rating: 120 to 277 VAC
• Start Type: Instant/Rapid
• Ballast Factor: 0.91
• Input Current: 0.39 to 0.92 Amp
• Wiring: Parallel
• Housing Material: Metal
• Ignition Time: 0.1 Second
• Current Crest Factor: 1.6
• Wire Type: Solid
• Wire Size: 18 AWG
• Application: Outdoor
• Applicable Standard: NEMA
• Input Voltage: 120/277 V
• Brand: Advance
