Advance IOP4P32LWN35I 120-277V Fluorescent Electronic Ballast

Product Description

The Advance IOP4P32LWN35I is a reliable fluorescent electronic ballast designed for 120-277V applications. It supports a maximum of four lamps with a wattage of thirty-two watts each. This ballast operates efficiently and is widely used in commercial and industrial lighting systems.

• Input voltage range: One hundred twenty to two hundred seventy-seven volts AC
• Maximum total harmonic distortion (THD): Ten percent
• Minimum starting temperature: Negative eighteen degrees Celsius

Product Highlights

Suitable for outdoor applications with quick ignition time. This ballast is crafted for metal housing and is compliant with UL and CSA standards.

Product Information

Standard Information

• Manufacturer: Advance
• UPC: 78108712519

Technical Specifications

• Input Current: 0.27 to 0.62 Amp
• Power Factor: 0.98
• Ballast Factor: 0.78
• Ignition Time: 0.1 Second
• Lamp Current Crest Factor: 1.6
• Wire Size: 18 AWG
• Package Weight: 1.0000 lb
• Country Of Origin: MEX
