Advance ICN2S40N35M ADV ICN2S40N35M (2)F40 T12 ELE BLST

Product Description

The Advance ICN2S40N35M is an electronic fluorescent ballast designed for high-frequency operation. This model supports two F40T12 lamps and operates efficiently with a normal output circuit. The ballast is suitable for input voltages ranging from one hundred twenty to two hundred seventy-seven volts.

• Input current is 0.62 Amperes at 120 volts.
• It has a high power factor of 0.98.
• Operates at frequencies of fifty to sixty Hertz.

Product Highlights

This ballast is ideal for applications requiring energy-efficient lighting solutions in commercial and industrial settings. It features rapid circuit technology for reliable lamp ignition and reduced energy waste.

Product Information

Standard Information

• Manufacturer: Advance
• UPC: 78108708038

Technical Specifications

• Input Voltage: 120 to 277 V
• Input Current: 0.62 A at 120 V, 0.26 A at 277 V
• Lamp Wattage: 40 W
• Ballast Factor: 0.85
• Maximum THD: 10%
• Temperature Range: Minimum starting temperature 50°F
• Size: 9.5 inches L x 1.3 inches W x 1 inch H
• Approval: UL, CSA
