Advance ICF2S18H1LDK 2-18W COMP 277 BAL

Product Description

The Advance ICF2S18H1LDK is a compact fluorescent ballast kit designed for efficient performance across a range of applications. This high-frequency, automatic restart ballast supports two lamps and is compatible with CFQ18W/G24Q lamps. It operates with an input voltage of one hundred twenty to two hundred seventy-seven volts AC, making it suitable for various installation environments.

• Input power ranges from thirty-five watts.
• Power factor rated at zero point ninety-eight.
• Dimensions of the ballast are four point ninety-eight inches in length, two point four inches in width, and zero point ninety-eight inches in height.

Product Highlights

This ballast ensures consistent lighting and energy efficiency. It boasts a maximum total harmonic distortion of ten percent, contributing to stable performance.

Product Information

Standard Information

• Manufacturer: Advance
• UPC: 78108711776
• Approval: UL, CSA, CEC

Technical Specifications

• Input Current: 0.3 Amp
• Frequency Rating: 50/60 Hertz
• Lamp Current Crest Factor: 1.5
• Ignition Time: 1.5 Seconds
• Wiring: Series
• Housing Material: Metal/Plastic
• Connection Type: Poke-In
