ADP HE47936C175B3122AP 3.0 Ton R-410A 36,000 BTU/h 17.5 in Cased-Coil

Product Description

The ADP HE47936C175B3122AP is a 3.0 ton evaporator coil designed for residential use with R-410A refrigerant. This unit is compatible with various furnace models and offers installation options in upflow, downflow, or horizontal setups.

• Durable insulated cabinet.
• Easy copper connections for brazing.
• Designed for optimal system efficiency with minimal air leakage.

Product Highlights

This evaporator coil delivers reliable performance and flexibility, ensuring it meets the demands of different HVAC configurations.

Product Information

Standard Information

• Model Number: HE
• Product Family: HE Series

Technical Specifications

• BTU Rating: 36,000 BTU/h
• Tonnage: 3.0 Ton
• Refrigerant Type: R-410A
• Coil Material: Copper
• Coil Casing: Cased
• Air Flow Direction: Upflow, Downflow, Horizontal
• Height: 31.5 inches
• Width: 17.5 inches
• Depth: 20.5 inches
• Drain Pan Material: Composite / Polymer
• Product Weight: 72 lbs
• Refrigeration Control Type: TXV
• Suction Line Size: 3/4 inches
