Adp 76793600 Evaporator Coil Drain Pan Vertical 15.5 Inches

Product Description

The ADP 76793600 is a vertical drain pan designed for use with slab-style evaporator coils in residential split-system air conditioning applications. Drain pans collect condensate water that forms on the evaporator coil during normal cooling operation, channeling it away from the air handler cabinet and into the condensate drain line. This pan is sized at 15.5 inches in width to match the HE Series slab coil footprint. HVAC technicians and installers use this component as a direct replacement when the original pan shows cracks, warping, rust, or biological growth that compromises drainage.

This drain pan is intended for vertical evaporator coil installations. It is sized to fit Slab A/B coil configurations in the 08 through 15 nominal tonnage range within the ADP HE Series lineup. Typical install scenarios include residential split-system replacements and maintenance service calls where the drain pan has failed or where standing water or overflow has been identified as the source of a callback.

Key Features

• 15.5-inch width matches the Slab A/B coil footprint for a direct-fit installation
• Vertical orientation designed for upflow and downflow air handler configurations using slab-style coils
• Sized to serve Slab A/B 08 through 15 nominal capacity coil models in the HE Series
• Replacement drain pan resolves condensate overflow, standing water, and cabinet moisture damage

Compatibility

Designed for use with ADP HE Series Slab A/B evaporator coils, nominal sizes 08 through 15, in vertical installations.

Installation Notes

Installation should be performed by a qualified HVAC technician. Shut down the air handler and disconnect power at the disconnect or breaker before removing or replacing the drain pan. Inspect the condensate drain line and trap for blockages before completing reassembly, as a restricted drain is often the root cause of pan overflow. Confirm the pan seats flush against the coil cabinet with no gaps that could allow condensate to bypass the pan.

Technical Specifications

• Item Type: Drain Pan
• Width: 15.5 inches
• Orientation: Vertical
• Used On: Slab A/B Evaporator Coil, sizes 08 to 15
• Series: HE Series

Standard Information

• Brand: ADP
• Manufacturer Part Number: 76793600
