Adey FL10302988 MagnaClean Professional 2

Product Description

The ADEY FL10302988 MagnaClean Professional 2 provides maximum protection for hydronic heating systems. Ideal for 3/4" copper and 1" NPT iron pipework, it features rapid in-line installation and integral flow-diverters that ensure 360° distribution for uniform flow around magnets, maximizing sludge capture. It captures both magnetic and non-magnetic debris.

• Ideal for 3/4" copper and 1" NPT iron pipework
• Features integral flow-diverters that ensure 360° distribution for uniform flow around magnets
• Equipped with a quick-release trigger and rapid-fit connectors for servicing and re-installation

Product Highlights

The MagnaClean Professional 2 offers full-flow valves for minimal pressure drop and easy dosing of ADEY treatment products.

Product Information

Standard Information

• Brand: ADEY
• Manufacturer Part Number: FL10302988

Technical Specifications

• Canister and Lid Material: Glass reinforced nylon
• Canister and Lid Volume: 0.15 gallons
• Canister and Lid Thread: Pressure thread
• Canister and Lid Flow configuration: Bi-directional – any port can be inlet
• Canister and Lid Main lid seal: EPDM
• Magnet Housing: Stainless steel
• Magnet Length: 5.90625"
• Magnet Diameter: 0.75"
• Bleed Valve Body material: Nickel plated brass
• Bleed Valve Screw: Nickel plated brass
• Bleed Valve Thread interface: Metric M6
• Bleed Valve Seals: EPDM
• Drain port Drain plug material: Nickel plated brass
• Drain port Drain plug thread: Metric M8
• Drain port Seals: EPDM
• Triple seal valves Body material: Nickel plated brass
• Triple seal valves Seals material: Long life PTFE ball seals
• Triple seal valves O ring material: EPDM 70 seals x 3
• Valve inlet/outlet: 3/4" compression
• Valve inlet/outlet (with adapters): 1" NPT female
• Valve to canister: EPDM
• Product Type: Dirt Eliminator
• Outlet Size: 3/4", 1"
• Inlet Size: 1", 3/4"
• Type: Magnetic
• BTU Boiler Range: Up to 150,000 BTUs
• Flow Rate: 13 GPM
• Height (in.): 8
• Cap Diameter (in.): 3.875
• Canister Diameter (in.): 3.125
