Acuity Brands CPX3P 2X2 three pane panel 30W 48W

Product Description

The ACUITY BRANDS CPX3P 2X2 is an LED flat panel designed for modern commercial lighting applications. This three-pane panel offers uniform illumination and high efficacy, leveraging the proven reliability of the CPX family. It features a distinctive design that enhances visual appeal while delivering excellent optical uniformity. Ideal for various settings requiring efficient and aesthetically pleasing lighting solutions.

• Modern Three-Pane Design for enhanced visual appeal
• Switchable Color Temperature (CCT) and Lumen Output for versatility
• Universal Voltage: 120-347V for broad compatibility

Product Highlights

Modern LED flat panel with switchable CCT and lumen output, offering high efficiency and uniform illumination.

Product Information

Standard Information

• Brand: ACUITY BRANDS
• Manufacturer Part Number: CPX3P 2X2

Technical Specifications

• Size: 2x2, 2x4
• Shape: Rectangular, Square
• Light Source: LED Dynamic
• Dynamic Feature: Switchable White
• Lumens: 2500-6000 LM (Switchable)
• CCT: 3500K, 4000K, 5000K (Variable, Field Selectable)
• CRI: 80
• Product Type: Panel
• Environmental Rating: Damp Location
• Certifications: CSA, DLC
• Dimming: 0-10V (Dim to 3-10%)
• Wattage: 30W, 48W
• Input Voltage: 120-277V, 120-347V (Universal)
• Color: White
• Mounting Type: Recessed, Surface, Suspended, T-Grid Ceiling
• Series: CPX3P
• Optics: Direct, General Diffused, Adjustable
• Controls/Network: Integral
• Emergency Feature: Integral
• Lumen Maintenance: 60000 hours
• Housing Type: IC
• Housing Depth: 2.2 inches
