ACR W1055 Stylus

Product Description

The ACR W1055 is a stylus with an M5 thread designed for precision work. It features a ball with a diameter of one millimeter and a carbide stem with a diameter of point eight millimeters. The stylus includes a tapered stainless steel base measuring eleven millimeters in diameter and fifty millimeters in length, with an overall length of fifty-five millimeters. It weighs twenty-two point four grams, making it suitable for various applications. The ball can be made of ruby or silicon nitride.

• M5 Thread for secure attachment
• Precision ball diameter of 1.0 mm
• Durable carbide stem

Product Highlights

This stylus is ideal for traders and professionals needing accuracy in their tasks.

Product Information

Standard Information

• Brand: ACR
• MPN: W1055

Technical Specifications

• Ball Diameter: 1.0 mm
• Stem Diameter: 0.8 mm
• Base Diameter: 11.0 mm
• Overall Length: 55.0 mm
• Base Length: 50.0 mm
• Stem Material: Carbide
• Base Material: Stainless Steel
• Ball Material: Ruby or Silicon Nitride
• Weight: 22.40 grams
