ACI ACI-A/TT1K-INW-12-4-GD Temperature Sensors Transmitter Immersion Series

Product Description

The ACI Transmitter Immersion Series with MPN ACI-A/TT1K-INW-12-4-GD is designed for accurate temperature measurement in various applications. This model features a two-wire, four to twenty milliamp loop powered output. An optional three-wire voltage output is also available. Each transmitter comes with zero and span adjustments for calibration in the field. The sensors are calibrated using equipment certified by NIST, ensuring high reliability.

• Two-wire design for easy installation
• Includes NIST Certified Calibration options
• High-quality encapsulation to protect against moisture

Product Highlights

This transmitter series includes a welded thermowell and is suited for applications needing a standard half-inch NPS process thread. For improved performance, it is recommended to use shielded cables during installation.

Product Information

Standard Information

• Brand: ACI: Automation Components, Inc.
• Model: ACI-A/TT1K-INW-12-4-GD

Technical Specifications

• Sensor Type: Immersion
• Output Signal: 4 to 20 mA, optional voltage
• Calibration: NIST certified
• Lead Wire Material: Etched Teflon
• Application: Temperature measurement
• Installation Recommendation: Use 18 to 22 AWG shielded cables
• Response Time: Depends on the epoxy used
• Ambient Conditions: Designed for robust uses
