ACI A/DLP-001-W-U-N-A-3 Diff Press Transmitter 0-1in w/o Display

Product Description

The ACI A/DLP-001-W-U-N-A-3 is a differential pressure transmitter designed for HVAC applications. This device has a measuring range of zero to one inch of water column, suitable for various pressure sensing tasks. Featuring a din rail clip for easy panel installation, it includes a pitot tube for duct mounting. This transmitter provides a field-selectable output that can be set to either four to twenty milliamperes, zero to five volts DC, or zero to ten volts DC.

• Uni-directional and bi-directional pressure measurement
• 0.5% accuracy ensures reliable readings
• Compact design with flexible installation options

Product Highlights

The A/DLP-001-W-U-N-A-3 is ideal for HVAC systems requiring precise pressure measurement.

Product Information

Standard Information

• Brand: ACI
• Supplier Part #: 141072

Technical Specifications

• Mount: Din Rail
• Range: 0-0.1, 0-0.2, 0-0.5, 0-1
• Output: 4-20mA, 0-5Vdc, 0-10Vdc
• Display: No
• Voltage: 16-36Vdc, 22-36Vdc, 24Vac
• Direction: Unidirectional, Bidirectional
• Pilot Tube: Yes
• Item Weight: 1.00 lbs per EA
