ACI A/DLP-001-W-U-N-A-0 Diff Press Transmitter 0-1in w/o Display

Product Description

The ACI A/DLP-001-W-U-N-A-0 is a differential pressure transmitter designed for HVAC applications. This unit measures pressure ranges from zero to one inch water column without a display. It is ideal for applications needing accurate pressure readings with easy installation.

• Accuracy of 0.5% for reliable measurements
• Field-selectable output options for flexibility
• Available in different pressure ranges

Product Highlights

This transmitter features unidirectional and bidirectional measurement capabilities, making it versatile for many HVAC settings.

Product Information

Standard Information

• Brand: ACI
• Part Number: A/DLP-001-W-U-N-A-0

Technical Specifications

• Pressure Range: 0-0.1, 0-0.2, 0-0.5, 0-1 inches water column
• Output Options: 4-20 mA, 0-5 VDC, 0-10 VDC
• Voltage Input: 16-36 VDC, 22-36 VDC, 24 VAC
• Display: No display included
• Direction: Unidirectional/Bidirectional
• Pilot Tube: None included
