Aci 106296 FS-5A Freeze Stat (6 ft Capillary) Automatic Reset 1 SPDT

Product Description

The ACI 106296 FS-5A is a freeze stat low limit controller designed for HVAC equipment to provide low-temperature cutout protection and prevent cooling coils from freezing. It uses a 6 ft capillary sensing element with automatic reset and provides one SPDT contact. The sensor mounts between heating and cooling coils on the supply side of the fan unit and responds to the lowest temperature along any 1-foot section of the sensing element.

• Low limit freeze stat for HVAC low-temperature cutout protection; mounts between heating and cooling coils on supply side of fan unit
• 6 ft capillary sensing element with automatic reset
• Single SPDT contact; responds to lowest temperature along any 1-foot section of sensing element

Product Highlights

Freeze stat controller with 6 ft capillary, automatic reset, and one SPDT contact for HVAC freeze protection

Product Information

Standard Information

• Brand: ACI
• Manufacturer Part Number: 106296
