Accupro ED99921222 Square End Mill 3/4 in 3 Flute Ticn

Product Description

The ACCUPRO ED99921222 is a single-end square end mill designed for metal cutting applications in milling machines and machining centers. Built from powdered metal and coated with titanium carbonitride (TiCN), this tool delivers improved wear resistance and surface hardness compared to standard high-speed steel. The 3/4-inch diameter cutting face is paired with a 2-1/4-inch length of cut and a 42-degree helix angle, which promotes efficient chip evacuation and reduced cutting forces. Three right-hand spiral flutes handle material removal across a broad range of metals and alloys. The tool is center-cutting, allowing plunge entry as well as conventional peripheral and slot milling.

This end mill is suited for job shops, production machining, and tool rooms working with steel, stainless, cast iron, and similar ferrous materials. The TiCN coating extends tool life in abrasive and high-heat cutting conditions. The 3/4-inch shank diameter fits standard collet chucks, end mill holders, and ER-style tooling commonly found on vertical and horizontal milling machines and CNC machining centers.

Key Features

• Powdered metal construction for improved toughness over standard HSS
• TiCN coating increases surface hardness and heat resistance for extended tool life
• 42-degree helix angle promotes efficient chip evacuation and smooth cutting action
• Center-cutting design allows plunge milling in addition to peripheral and slot operations
• Right-hand cut and right-hand flute direction compatible with standard spindle rotation
• No chipbreaker geometry for clean, continuous cuts in suitable materials

Compatibility

Designed for use with standard 3/4-inch collet chucks, end mill holders, and ER-style toolholders on vertical or horizontal milling machines and CNC machining centers.

Installation Notes

Installation should be performed by a qualified machinist or toolroom technician. Ensure the machine spindle is fully stopped and locked out before loading or removing the end mill. Insert the shank to the full recommended engagement depth in the toolholder and torque the retention mechanism per the toolholder manufacturer specifications. Inspect the cutting edges and coating for chips or damage before each use.
