Accupro 95168617 Corner Chamfer End Mill 1/2 in 4 Flute

Product Description

The ACCUPRO 95168617 is a solid carbide corner chamfer end mill designed for precision chamfering and edge-breaking operations on ferrous and non-ferrous materials. Built from micrograin solid carbide, it delivers the rigidity and edge retention needed in demanding machining environments. The 45-degree chamfer angle and 0.0150-inch chamfer width produce consistent, repeatable edge geometry. The nACRo coating provides thermal resistance and reduced friction, extending tool life in high-speed applications. This single-end, centercutting tool suits machinists and tool-and-die professionals running CNC mills or manual knee mills where controlled chamfer geometry is required.

This end mill is suited for use in CNC machining centers and manual milling operations where corner chamfering, edge deburring, or beveling is required. The 1/2-inch diameter and 1-1/4-inch length of cut make it appropriate for a range of workpiece sizes in production and job-shop environments. The regular length type and 1/2-inch shank diameter fit standard collet chucks and end mill holders commonly found in shop inventories.

Key Features

• Solid micrograin carbide construction for high rigidity and edge retention
• nACRo coating for reduced friction and improved thermal resistance
• 45-degree chamfer angle with 0.0150-inch chamfer width for precise edge geometry
• Variable helix design reduces chatter and improves chip evacuation
• Centercutting capability allows plunge entry into the workpiece
• Right-hand cutting and right-hand flute direction for standard spindle compatibility

Compatibility

Designed as an OEM-style replacement or direct-use chamfer end mill for CNC machining centers and manual mills accepting a 1/2-inch shank diameter with standard collet or end mill holder tooling.

Installation Notes

Installation should be performed by a qualified machinist following standard tooling procedures. Ensure the machine spindle is fully stopped and locked before installing or removing the tool. Secure the 1/2-inch shank firmly in a clean, properly sized collet or end mill holder to the torque specifications listed by the toolholder manufacturer. Verify runout with a dial indicator before beginning cuts to protect both the tool and the workpiece.
