Accupro 95168449 Corner Chamfer End Mill 5/8 in 4 Flute

Product Description

The ACCUPRO 95168449 is a solid carbide corner chamfer end mill designed for precision chamfering and edge-breaking operations on ferrous and non-ferrous workpieces. It measures 5/8 inches in diameter with a 1-5/8 inches length of cut and a 3-1/2 inches overall length. The 45-degree chamfer angle and 0.0150 inch chamfer width deliver consistent, repeatable edge geometry. The AlTiN coating provides elevated heat resistance and extended tool life in high-speed cutting environments. A variable helix design reduces chatter and improves surface finish. This tool is intended for use by machinists and CNC operators in job shop, production, and tool room settings.

This end mill suits applications where controlled chamfer geometry is required on milled parts, drilled holes, or profiled edges. Its centercutting capability allows direct plunging into the workpiece when needed. The right-hand flute direction and right-hand cutting geometry are standard for conventional CNC milling setups. With a micrograin carbide substrate, it performs reliably in demanding cuts on steel, stainless, and hardened alloys. The 5/8 inches shank diameter fits standard ER and end mill holders commonly found on vertical and horizontal machining centers.

Key Features

• 45-degree chamfer angle with 0.0150 inch chamfer width for precise edge geometry
• AlTiN coating for high-temperature resistance and extended tool life
• Variable helix reduces vibration and improves surface finish
• Centercutting design allows direct plunge entry
• Micrograin solid carbide substrate for rigidity and wear resistance
• Right-hand spiral flutes for standard CNC milling compatibility

Compatibility

Designed as an OEM-style replacement for solid carbide corner chamfer end mills used in standard CNC milling applications requiring a 5/8 inches diameter, 5/8 inches shank, and 45-degree chamfer geometry.

Installation Notes

Installation should be performed by a qualified machinist or CNC operator. Ensure the machine spindle is fully stopped and locked out before loading or removing the tool. Seat the shank fully and evenly in the tool holder and torque the set screw or collet nut to the holder manufacturer specification. Verify runout with a dial indicator before initiating a cut to protect both the tool and the workpiece.
