Accupro 35412 Corner Chamfer End Mill 1 in 5 Flute Tialn

Product Description

The ACCUPRO 35412 is a corner chamfer end mill designed for precision chamfering and edge-breaking operations on metal workpieces. Built from powdered metal and coated with TiAlN (titanium aluminum nitride), it delivers extended tool life in demanding cutting environments. The 35412 measures 1 inch in cutting diameter with a 3-inch length of cut (LOC) and an overall length (OAL) of 5.25 inches. The 0.75-inch shank diameter provides rigid tool holding. With five flutes and a 30-degree helix angle, this end mill balances chip evacuation with surface finish quality. Right-hand cutting and right-hand flute direction are standard. Centercutting geometry allows plunge entry where required.

This end mill is suited for use in CNC machining centers and manual milling machines across job shops, tool rooms, and production environments. It is intended for ferrous and hardened materials where TiAlN coating provides thermal resistance and wear protection. The fine pitch and five-flute configuration make it well suited for finishing passes and chamfer work on steel, stainless, and cast iron. Machinists and tool and die professionals are the primary users of this type of tooling.

Key Features

• TiAlN coating for elevated heat resistance and extended tool life in ferrous materials
• Powdered metal substrate for consistent hardness and toughness throughout the tool body
• Five-flute, fine-pitch design balances chip clearance and surface finish quality
• 30-degree helix angle supports smooth cutting action and reduced chatter
• Centercutting capable for plunge milling entry
• Right-hand cut and right-hand flute direction for standard spindle compatibility

Compatibility

Designed as an OEM-style replacement or direct-use corner chamfer end mill for standard 0.75-inch collet or end mill holders in CNC and manual milling setups.

Installation Notes

Installation of end mills should be performed by a qualified machinist following machine tool manufacturer guidelines. Ensure the spindle is fully stopped and the machine is in a safe, locked-out state before changing tooling. Use a properly sized collet or end mill holder matched to the 0.75-inch shank diameter. Verify runout with a dial indicator after seating to confirm proper tool holding before beginning a cut.
