Accupro 35373 Corner Chamfer End Mill 0.5in 4 Flute

Product Description

The ACCUPRO 35373 is a corner chamfer end mill designed for milling chamfers and angled edges on ferrous and non-ferrous workpieces. It is ground from powdered metal tooling stock, which provides a finer grain structure and improved edge retention compared to standard high-speed steel. With a 0.5 inch cutting diameter, a 3 inch length of cut, and a 4-flute configuration, this tool is suited for finishing passes and controlled material removal. The bright, uncoated surface finish makes it easy to inspect for wear. It is a centercutting design, allowing plunge entry into the workpiece when the application requires it.

This end mill is used in vertical machining centers, manual knee mills, and CNC milling applications where chamfering, edge breaking, or angled profiling is required. The 30-degree helix angle provides a balance between cutting action and chip evacuation on a range of materials. With a 1/2 inch shank diameter and 5 inch overall length, it fits standard ER and end mill holders commonly found in machine shops performing precision part work. Right-hand cutting and right-hand flute direction are standard for conventional and climb milling operations.

Key Features

• Powdered metal construction for improved grain structure and edge retention over standard HSS
• 4-flute design supports finish milling and controlled stock removal
• Centercutting geometry allows direct plunge entry
• Bright, uncoated finish suitable for inspection and general-purpose use
• 30-degree helix angle balances chip flow and cutting smoothness
• Right-hand cut and right-hand flute direction for standard milling setups

Compatibility

Designed as an OEM-style replacement or direct-use corner chamfer end mill for standard 1/2 inch end mill holders and collet systems used in vertical and CNC milling operations.

Installation Notes

Installation is performed by a machinist or toolroom professional. Ensure the machine spindle is fully stopped and locked out before changing tooling. Seat the 1/2 inch shank fully into the holder to the recommended gauge line and torque the retention nut or set screw per the holder manufacturer specification. Inspect the cutting edges for chips or damage before each use.
