Accupro 35332 Corner Chamfer End Mill 1.5 in 6 Flute

Product Description

The ACCUPRO 35332 is a corner chamfer end mill designed for milling operations requiring a chamfered edge profile at the tool corner. Built from powdered metal, this 6-flute cutter offers a 1.5-inch diameter with a 3-inch length of cut and an overall length of 5.5 inches. The 1.25-inch shank diameter provides solid tool holding in standard milling chucks and collets. A 30-degree helix angle and coarse pitch flute geometry support chip evacuation during profiling and chamfering passes. The bright, uncoated finish suits a range of ferrous and non-ferrous workpiece materials. Center-cutting capability allows plunge entry without a pre-drilled start hole.

This end mill is suited for use in vertical machining centers, knee mills, and CNC milling machines running production or toolroom work. The corner chamfer geometry is used to break sharp edges, generate chamfered features, or blend transitions between surfaces in metal fabrication, die and mold work, and general machining. Right-hand cutting and right-hand flute direction are standard for conventional milling setups. The 6-flute count supports higher feed rates in finish and semi-finish passes where surface quality matters.

Key Features

• Corner chamfer geometry for edge-breaking and chamfer milling operations
• 1.5-inch cutting diameter with 3-inch length of cut
• 6 flutes with coarse pitch for efficient chip removal
• 30-degree helix angle promotes smooth cutting action
• Center-cutting design allows direct plunge entry
• Bright, uncoated powdered metal construction for broad material compatibility

Compatibility

Designed as a standard-shank corner chamfer end mill with a 1.25-inch shank diameter, compatible with milling tool holders and collet chucks sized for 1.25-inch shanks in vertical and horizontal milling machine setups.

Installation Notes

Installation is performed by a machinist or toolroom technician. Always power down and lock out the machine spindle before changing tooling. Seat the shank fully in the tool holder and torque set screws or collet nuts to the tool holder specification. Verify runout with a dial indicator before beginning a cut, as excessive runout on a 6-flute cutter accelerates uneven wear.
