Accupro 33060 Corner Chamfer End Mill 0.625in 4 Flute

Product Description

The ACCUPRO 33060 is a corner chamfer end mill designed for precision milling operations in metal fabrication and machining environments. Built from powdered metal, it measures 0.625 inches in diameter with a 1.625-inch length of cut and a 3.75-inch overall length. The 5/8-inch shank diameter provides stable tool holding in standard collet and end mill holders. A bright, uncoated finish makes it well suited for general-purpose cutting where coating is not required. Licensed machinists and CNC operators working in job shops, tool rooms, and production facilities are the typical end users for this tool.

This end mill is used for chamfering corners and edges on ferrous and non-ferrous workpieces in both manual milling and CNC machining applications. The fine pitch, 4-flute configuration supports smooth chip evacuation and finish quality on a range of materials. The 30-degree helix angle balances cutting efficiency with edge strength. Right-hand cutting and right-hand flute direction are standard for conventional and climb milling on vertical and horizontal mills.

Key Features

• Powdered metal construction for wear resistance in general-purpose machining
• 4-flute, fine-pitch design for improved surface finish and chip control
• 30-degree helix angle balances cutting efficiency with tool stability
• Bright, uncoated finish suited for dry cutting and standard coolant applications
• Centercutting geometry allows plunge entry into the workpiece
• Right-hand cut and right-hand flute for conventional milling setups

Compatibility

Designed as an OEM-style replacement or direct-use corner chamfer end mill for standard 5/8-inch end mill holders, collet chucks, and milling machines accepting straight shank tooling.

Installation Notes

Installation is performed by qualified machinists or CNC setup technicians. Ensure the machine spindle is fully stopped and locked out before changing tooling. Seat the shank fully into the holder and torque the set screw or collet nut to the tool holder specification. Verify runout with a dial indicator before beginning a cut to prevent premature edge wear.
