Accupro 2500033 Roughing End Mill 1/4 in 4 Flute Carbide

Product Description

The ACCUPRO 2500033 is a single-end roughing end mill designed for aggressive material removal in milling operations. Built from micrograin solid carbide and coated with TiCN (Titanium Carbonitride), it delivers extended tool life in demanding cutting applications. The 1/4 inch diameter cutter features 4 flutes with a right-hand cutting and flute direction, a 3/4 inch length of cut, and a 2-1/2 inch overall length. The TiCN coating improves surface hardness and reduces friction at the cutting edge, making it well suited for high-speed roughing passes where heat buildup is a concern. This tool is installed and operated by machinists and CNC tool operators in job shop and production environments.

This roughing end mill is intended for use in vertical machining centers, CNC mills, and manual knee mills where rapid stock removal is required. The regular-length geometry and 1/4 inch shank make it a practical choice for slotting, profiling, and pocketing operations in ferrous and non-ferrous materials. The non-centercutting design means it is best used for peripheral and slot cutting rather than plunge operations. No extended reach or variable helix geometry is present, keeping the tool suited to standard-depth applications.

Key Features

• Micrograin solid carbide construction for rigidity and wear resistance
• TiCN coating improves hardness and reduces cutting-edge friction
• 4-flute, right-hand cut configuration optimized for roughing passes
• 1/4 inch shank diameter with tight tolerance: +0.0001 to -0.0004 inches
• Non-centercutting design suited for peripheral milling and slotting
• Regular length geometry for use in standard-depth milling setups

Compatibility

Designed as an OEM-style replacement and standard fitment roughing end mill for 1/4 inch collets and end mill holders used in CNC and manual milling machines accepting right-hand, single-end tooling.

Installation Notes

Installation is performed by a qualified machinist or CNC operator. The machine spindle must be fully stopped and locked out before inserting or removing the end mill from the collet or tool holder. Confirm the holder bore matches the 1/4 inch shank diameter and that runout is within acceptable limits before beginning a cut. Because this is a non-centercutting tool, do not use it for direct plunge entry into solid material.
