Accupro 14797375 Ball End Mill 0.015 in 2 Flute Carbide

Product Description

The ACCUPRO 14797375 is a solid carbide ball end mill designed for precision milling in tight tolerances and complex contour work. With a 0.015 inch cutting diameter and a 0.045 inch length of cut, this tool is built for micro-milling applications where dimensional accuracy is critical. The AlTiN coating provides heat resistance and extended tool life in hard and abrasive workpiece materials. The micrograin carbide substrate supports the fine edge geometry required at this diameter. Machinists and tool-and-die professionals working on CNC machining centers will find this end mill suited for finishing passes on hardened steels, alloys, and similar materials.

This ball end mill is intended for use in CNC milling applications requiring fine detail work, including die cavities, mold work, and contour profiling at small scales. The 0.015 inch diameter makes it appropriate for high-precision work in aerospace, medical device, and mold-and-die industries. It installs in a 1/8 inch shank collet or chuck on a CNC vertical or horizontal machining center. The single-end configuration means the cutting end is fixed to one end of the tool only.

Key Features

• 0.015 inch ball nose cutting diameter for micro-milling and fine contour work
• Solid micrograin carbide construction for rigidity and edge retention at small diameters
• AlTiN coating for improved heat resistance and tool life in hard materials
• 30-degree right-hand spiral helix with 2 flutes for efficient chip evacuation
• 1/8 inch shank diameter for compatibility with standard collet systems
• Single-end design with 1.5 inch overall length for standard reach applications

Compatibility

Designed for use in CNC machining centers accepting a 1/8 inch shank end mill. Suitable for right-hand spindle rotation setups standard to vertical and horizontal CNC milling equipment.

Installation Notes

Installation should be performed by a qualified machinist or CNC setup technician. Power down and lock out the spindle before inserting or removing any tooling. Seat the shank fully into the collet or tool holder to the recommended engagement depth before torquing the retention nut. At this diameter, handle with care to avoid chipping the cutting edge during setup and storage.
