Accupro 12182167 Square End Mill 7/32 in 3 Flute Carbide

Product Description

The ACCUPRO 12182167 is a solid carbide square end mill designed for precision milling in metal and hard-material applications. It features a 7/32 inch (0.2188 inch) cutting diameter, a 3/8 inch length of cut, and a 1/4 inch shank diameter with an overall length of 2 inches. The stub-length configuration provides added rigidity, reducing deflection during aggressive cuts. The 40-degree helix angle combined with three spiral flutes promotes efficient chip evacuation and smooth cutting action. A titanium carbonitride (TiCN) coating increases surface hardness and wear resistance, extending tool life in ferrous and non-ferrous materials. Installed by machinists and tool-and-die professionals.

This end mill is suited for milling slots, pockets, profiles, and contours in steel, stainless, aluminum, and similar workpiece materials. The stub-length geometry makes it especially effective in setups where overhang must be minimized to maintain dimensional accuracy. Centercutting capability allows direct plunge entry without a pre-drilled hole, adding flexibility in CNC and manual milling applications. Right-hand cut and right-hand flute orientation follow standard spindle conventions on most vertical mills and machining centers.

Key Features

• Solid carbide micrograin substrate for hardness and edge retention
• TiCN coating for improved wear resistance and reduced friction
• 40-degree helix spiral flutes for efficient chip evacuation
• Centercutting design allows direct plunge milling
• Stub-length body minimizes deflection in tight-clearance setups
• Right-hand cut and right-hand flute for standard spindle compatibility

Compatibility

Designed as a direct-fit replacement end mill for 1/4 inch shank toolholders, collets, and end mill holders on standard CNC machining centers and manual vertical mills.

Installation Notes

Installation and tool changes must be performed with the spindle fully stopped and the machine in a safe, locked-out state per facility lockout/tagout procedures. Seat the 1/4 inch shank fully into the collet or toolholder and torque the retention nut to the toolholder manufacturer specification. Verify runout at the cutting edge before beginning a production run. Inspect the TiCN coating and cutting edges for chipping or wear during routine tool changes.
