Accupro 12181886 Corner Radius End Mill 1in 3-flute Carbide

Product Description

The ACCUPRO 12181886 is a solid carbide corner radius end mill designed for precision milling operations in demanding machining environments. It features a 1 inch cutting diameter, a 1-3/4 inch length of cut, and a 0.09 inch corner radius that blends floor-to-wall transitions and reduces stress concentrations at part corners. The tool is coated with AlTiN (aluminum titanium nitride) for elevated heat resistance and extended tool life in hardened steels and high-temperature alloys. With a 4 inch overall length and a 40-degree helix angle, it delivers efficient chip evacuation and smooth surface finishes. Machinists and CNC operators install this tool in vertical and horizontal machining centers.

This end mill suits finish and semi-finish milling applications in mold and die work, aerospace components, and precision part manufacturing. The single-end, centercutting design allows plunge entry as well as peripheral and slot milling. The right-hand flute direction and right-hand cutting direction are standard for conventional CNC setups. The micrograin carbide substrate provides toughness and edge retention when working ferrous and non-ferrous materials at high feed rates and surface speeds.

Key Features

• 0.09 inch corner radius reduces stress risers and improves corner blending on finished surfaces
• AlTiN coating provides high-temperature oxidation resistance for dry and semi-dry cutting conditions
• Micrograin solid carbide substrate delivers superior edge retention and rigidity
• 40-degree helix angle promotes efficient chip evacuation and reduces cutting forces
• Centercutting design enables direct plunge entry without a pre-drilled pilot hole
• 3 flutes balance chip clearance with cutting edge contact for finish milling passes

Compatibility

Designed as a standard-shank solid carbide corner radius end mill with a 1 inch shank diameter, compatible with ER, CAT, BT, and HSK toolholders sized for 1 inch straight shanks in CNC machining centers.

Installation Notes

Installation is performed by qualified machinists or CNC setup technicians. The machine spindle must be stopped and locked out before inserting or removing the tool from the holder. Ensure the toolholder collet or set-screw bore matches the 1 inch shank diameter and that the tool is seated to the proper gauge length before tightening. Inspect the cutting edges for chipping before each use; carbide end mills should not be forced into a worn or undersized bore.
