Accupro 12180443 Square End Mill 3/8 in 4 Flute Carbide

Product Description

The ACCUPRO 12180443 is a 4-flute solid carbide square end mill designed for precision metal removal in demanding machining environments. The 0.375-inch diameter cutting edge pairs with a 40-degree helix angle and spiral flute geometry to produce efficient chip evacuation and smooth surface finishes. An AlTiN coating provides heat and oxidation resistance, extending tool life in high-speed and dry-cutting applications. The micrograin carbide substrate delivers edge retention and rigidity well beyond standard HSS tooling. This end mill is centercutting, allowing direct plunge entry into workpiece material without a pre-drilled pilot hole.

This end mill is suited for milling ferrous and non-ferrous metals, including hardened steels, stainless, and cast iron, in CNC machining centers and manual mills. With a 1.5-inch length of cut and 3.5-inch overall length, it handles standard-depth slotting, profiling, and pocketing operations. The right-hand cut and right-hand flute configuration is the industry-standard orientation for conventional spindle setups. Variable index spacing reduces harmonic chatter during aggressive cuts.

Key Features

• Solid micrograin carbide construction for superior hardness and edge retention
• AlTiN finish resists heat and oxidation in high-speed and dry-cutting conditions
• 40-degree helix angle with spiral flute geometry promotes efficient chip evacuation
• Centercutting design allows direct plunge milling without a pilot hole
• Variable index flute spacing reduces chatter and vibration during heavy cuts
• Right-hand cut and right-hand flute for standard CNC and manual mill spindle compatibility

Compatibility

Designed as a direct-fit replacement or upgrade for 3/8-inch shank square end mill applications in CNC machining centers and manual milling machines using standard ER or straight-shank collet systems.

Installation Notes

Installation should be performed by a machinist or qualified CNC operator following shop safety protocols. Ensure the spindle is fully stopped and the machine is in a safe state before changing tooling. Seat the shank fully into the collet or tool holder and torque the retention mechanism to the tool holder specification. Verify runout with a dial indicator before beginning a production cut to confirm proper seating and minimize premature edge wear.
