Accupro 12179729 Square End Mill 3/8 in 3 Flute Carbide

Product Description

The ACCUPRO 12179729 is a solid carbide square end mill designed for precision milling of ferrous and non-ferrous materials in CNC and manual machining applications. The cutting diameter measures 0.375 inches with a matching 0.375-inch shank diameter, a 0.625-inch length of cut, and a 2.0-inch overall length. It features three spiral flutes ground to a 40-degree helix angle and is finished with an AlTiN (aluminum titanium nitride) coating that improves heat resistance and tool life at elevated cutting speeds. Micrograin carbide construction contributes to edge sharpness and wear resistance. This end mill is centercutting, allowing plunge entry directly into a workpiece.

This end mill is suited for side milling, slotting, and plunge operations in machine shops, production facilities, and toolrooms. Its stub-length profile provides added rigidity when clearance is not a limiting factor, making it a practical choice for general-purpose profiling and finishing passes. The right-hand cut and right-hand spiral flute geometry is standard for conventional CNC spindle setups. The AlTiN finish makes it well suited for dry or high-speed cutting where coolant use is limited.

Key Features

• Solid micrograin carbide construction for edge retention and rigidity
• AlTiN coating for elevated heat resistance and extended tool life
• 40-degree helix angle promotes smooth chip evacuation
• Centercutting design allows direct plunge entry
• Stub-length OAL of 2.0 inches increases stiffness and reduces deflection
• Right-hand cut with right-hand spiral flute — compatible with standard CNC spindle rotation

Compatibility

Designed as a direct-fit replacement or standard tooling selection for 3/8-inch collets, shrink-fit holders, and set-screw end mill holders used in CNC machining centers and manual knee mills.

Installation Notes

Installation should be performed by a qualified machinist or CNC setup technician. Ensure the machine spindle is fully powered down and locked out before loading or changing tooling. Verify the holder bore and collet size match the 0.375-inch shank diameter before tightening. Confirm runout tolerance is within acceptable limits after tool installation to protect both the end mill and the workpiece.
