Accupro 12176843 Corner Radius End Mill 1 in 2 Flute Altin

Product Description

The ACCUPRO 12176843 is a single-end corner radius end mill ground from micrograin solid carbide and coated with AlTiN (aluminum titanium nitride) for extended tool life in high-heat cutting applications. It features a 1 inch cutting diameter, a 1-3/4 inch length of cut, and a 0.09 inch corner radius that reduces stress concentrations and improves surface finish on profiled pockets and shoulders. The 40-degree helix angle promotes efficient chip evacuation and smooth cutting action. With a 1 inch shank diameter and 4 inch overall length, this end mill mounts directly in standard ER or end mill holders found on CNC machining centers and manual mills. It is center-cutting, allowing direct plunge entry into the workpiece.

This end mill is suited for peripheral milling, slotting, and profiling operations on ferrous and non-ferrous materials where a radiused corner is required. The AlTiN coating makes it well-suited for dry or minimal-lubrication machining of hardened steels, cast iron, stainless, and high-temperature alloys. It is used in job shops, production machining environments, and tool rooms where consistent corner geometry and dimensional accuracy are required. The right-hand spiral flute geometry is compatible with conventional CNC vertical and horizontal machining center setups.

Key Features

• Micrograin solid carbide substrate for increased hardness and wear resistance
• AlTiN coating extends tool life in high-temperature, dry-cut applications
• 0.09 inch corner radius reduces edge chipping and improves part surface finish
• 40-degree helix angle for efficient chip evacuation and reduced cutting forces
• Center-cutting design allows direct plunge milling without a pre-drilled entry hole
• Right-hand cut and right-hand spiral flute for standard CNC spindle compatibility

Compatibility

Designed as an OEM-style replacement or direct-application corner radius end mill for use in standard 1 inch bore end mill holders, collet chucks, and hydraulic tool holders on CNC machining centers and manual mills.

Installation Notes

Installation should be performed by a qualified machinist or CNC setup technician. Ensure the machine spindle is fully stopped and the tool holder is clean and free of debris before seating the shank. Torque the tool holder to the machine manufacturer's specification using the appropriate spanner or torque wrench. Confirm tool runout with a dial indicator after clamping before beginning any cut cycle.
