Abz Manufacturing 300ABZ719953BFV 3 719-953 Butterfly Valve W/Lever Hdl

Product Description

The ABZ MANUFACTURING 300ABZ719953BFV is a general-purpose ABZ 709/719 resilient-seated butterfly valve machined for long life and resiliency. Its slim profile permits maximum open fluid flow. This sturdy valve meets industry standards for durability and tight shut-off. It features double-V stem self-seals that protect stem areas during vacuum or pressure use.

• Resilient-seated butterfly valve
• Slim profile permits maximum open fluid flow
• Unique double-V stem self-seals that protect stem areas during vacuum or pressure use

Product Highlights

The ABZ butterfly valve offers durability and tight shut-off, meeting API, ASME, and ANSI standards. It is designed for maximum open fluid flow.

Product Information

Standard Information

• Brand: ABZ MANUFACTURING
• Manufacturer Part Number: 300ABZ719953BFV

Technical Specifications

• Series/Model: Model 719-953
• Nominal Size: 3 IN
• Pressure Rating: 150 PSI
• Body Material: Cast Iron
• Operator Type: Lever Handle
• Trim Material: 316 Stainless Steel Disc
• Industry Standards: API 609 Category A, ASME 16.1/16.5, ASME 16.34 And MSS SP67
• Design Tested In Accordance With: API 598
• Lead Free: No
• Other Physical Dimension: 5/8-11 UNC Thread, 6 IN Bolt Circle Diameter
• Additional Specifications: Number Of Holes: 4
• Item Name: Butterfly Valve
• Type: Lug Style, Resilient Seated, General Purpose
