ABB - U065F1 Fused Pull-Out AC Disconnect Switch 120/240 VAC 60 A

Product Description

ABB - U065F1 is a fused pull-out AC disconnect switch designed for 120/240 VAC applications. It provides a reliable option for disconnecting power. This switch is rated for sixty amps and is suitable for handling ten horsepower loads. It features a NEMA 3R enclosure for outdoor installation, ensuring protection against rain and snow.

• Amperage rating of 60 A
• NEMA 3R enclosure
• Dimensions of nine inches high by five inches wide by two and one-eighth inches deep

Product Highlights

The U065F1 is designed for safe operation during maintenance. Its removable pullers allow for easy access while the door has padlock provisions to prevent unauthorized access. The robust construction reduces the installation time.

Product Information

Standard Information

• Manufacturer: ABB - Midwest Electric
• Manufacturer Part Number: U065F1

Technical Specifications

• Voltage Rating: 120/240 VAC
• Horsepower: 10 hp
• Amperage Rating: 60 A
• Short Circuit Current Rating: 10 kA
• Enclosure Type: NEMA 3R
• Material: Steel
• Mounting Type: Surface
• Finish: Galvanized/Powder Coated
• Standards/Approvals: ARRA Compliant, Buy American Act Compliant, RoHS Compliant, cUL/UL Listed
