Abb TV10-14R-XV 12-10 Awg Ring Terminal

Product Description

The ABB TV10-14R-XV is a ring terminal connector designed for use with 12 to 10 AWG wire. Ring terminals provide a secure, vibration-resistant electrical connection by fastening directly to a stud or screw, making them a standard component in control panels, motor connections, and field wiring applications. This connector is suited for electricians and panel builders who need a reliable, code-compliant termination method for copper conductors in industrial and commercial electrical systems.

Ring terminals in the 12-10 AWG range are commonly used in residential and light commercial electrical installations, HVAC equipment wiring, motor control centers, and distribution panels. The TV10-14R-XV is appropriate for applications where a permanent, bolted connection is required and where the terminal must resist pull-out and maintain contact integrity under load.

Key Features

• Accepts 12 to 10 AWG copper conductors
• Ring-style termination for bolted stud or screw connections
• Vibration-resistant mechanical connection
• Suitable for control panel and field wiring applications
• Consistent crimp geometry for repeatable terminations

Compatibility

Designed as an OEM-style ring terminal for use with 12 to 10 AWG copper wire in standard electrical termination applications.

Installation Notes

Installation should be performed by a licensed electrician following applicable NEC requirements. De-energize the circuit and verify zero voltage with a meter before terminating any conductors. Use a calibrated crimping tool rated for the terminal and wire gauge to ensure a proper mechanical and electrical crimp. Do not solder over a crimped ring terminal, as this can create a stress point at the barrel transition.

Technical Specifications

• Wire Range: 12-10 AWG
• Terminal Type: Ring
• Package Weight: 6.25 pounds
• Package Dimensions: 10.82 inches x 7.81 inches x 4.96 inches
• UPC: 72849414414

Standard Information

• Brand: ABB
• Manufacturer Part Number: TV10-14R-XV
