Abb TV10-10R-XV Circuit Breaker

Product Description

The ABB TV10-10R-XV is a circuit breaker designed for electrical distribution and overcurrent protection applications. Circuit breakers in this product family are installed by licensed electricians in residential, commercial, and light industrial panelboards and load centers. This unit provides reliable fault interruption and circuit protection, and its compact form factor suits a range of enclosure and switchboard configurations. The TV10-10R-XV is a direct-replacement-style device suited for service work and new construction alike.

This circuit breaker is appropriate for use in electrical distribution panels requiring overcurrent protection. It is typically installed during panel construction, service upgrades, or breaker replacement projects. Licensed electricians and electrical contractors are the primary installers. The physical dimensions of 10.82 inches by 7.81 inches by 4.96 inches and weight of 7.5 pounds are consistent with a molded-case or larger frame breaker intended for branch or feeder circuit applications.

Key Features

• Molded-case or frame-style construction suited for distribution panel and load center installation
• Compact footprint at 10.82 x 7.81 x 4.96 inches fits standard enclosure configurations
• 7.5-pound unit weight consistent with robust internal fault-interruption components
• Direct OEM-style replacement form factor for service and maintenance applications

Compatibility

Designed as an OEM-style replacement circuit breaker for electrical distribution and panelboard applications where ABB TV-series breakers are specified.

Installation Notes

Installation must be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and all applicable local codes. De-energize and lock out the panel before removing or installing any breaker. Verify that bus bar configuration, pole count, and interrupting rating match the application requirements before installation. Do not exceed the breaker's rated current for the intended circuit.

Technical Specifications

• Dimensions (L x W x H): 10.82 inches x 7.81 inches x 4.96 inches
• Weight: 7.5 pounds
• UPC: 72849414413

Standard Information

• Brand: ABB
• Manufacturer Part Number: TV10-10R-XV
