ABB TLMQ812RCU 8 Circ Mnlug 125A Outdoor Surface

Product Description

The ABB TLMQ812RCU is a convertible load center designed for outdoor use. This unit comes as a main lug but allows for the option of installing a main breaker. It is rated for ambient temperatures up to sixty to seventy-five degrees Celsius, making it appropriate for use with service entrance equipment when installed according to local electrical codes.

• Accommodates up to eight one-inch breakers.
• Rated for 125 amps and includes a copper bus.
• Constructed with a weatherproof outdoor enclosure.

Product Highlights

The load center is versatile and reliable, ideal for various electrical setups.

Product Information

Standard Information

• Category: Weatherproof Distribution Equipment
• Grouping: Single Phase - USA

Technical Specifications

• 1" Space: 8
• Amperage: 125 A
• Circuit Breaker Style: Plug-In
• Device Type: Main Lug
• Door: Yes
• Enclosure: Outdoor
• Enclosure Type: NEMA 3R
• Input/Output Voltage: 120/240V AC
• Bus Material: Tin Plated Copper
• Current Rating: 125 Amp
• Maximum Number of Circuits: 8
• Size: 11-1/4 Inch Width x 3-1/4 Inch Depth x 11-1/8 Inch Height
• Main Wire Size: 6 to 1 AWG (Copper/Aluminum)
