Abb tlm3220ccu Field Convertible Combination Starter 200A

Product Description

The ABB tlm3220ccu is a field-convertible combination starter designed for industrial control and automation applications. This unit supports up to 200 amps and accommodates 32 circuits with 22k interrupting capacity, making it suitable for demanding electrical distribution and motor control environments. It is intended for installation by licensed electricians and industrial automation technicians working on commercial and industrial power distribution systems. The combination design integrates disconnect and control functions into a single enclosure, reducing panel space and simplifying wiring.

The tlm3220ccu is used in commercial and industrial facilities where centralized motor control or branch circuit distribution is required. Its field-convertible design allows configuration adjustments on-site without returning the unit to the factory, supporting flexible project requirements. Typical applications include motor control centers, industrial machinery panels, and large commercial electrical distribution systems.

Key Features

• Field-convertible design allows on-site configuration changes
• 200 amp maximum current rating for high-capacity distribution
• 32-circuit capacity for multi-branch industrial panel applications
• 22k interrupting capacity for fault protection in industrial environments
• Combination starter configuration integrates disconnect and control in one unit

Compatibility

Designed as an OEM-style replacement or direct-install component for industrial motor control and combination starter applications requiring a 200 amp, 32-circuit field-convertible unit.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and all applicable local codes. De-energize and lock out the power supply before beginning any installation or service work on this unit. Verify that the panel bus rating and available fault current at the installation point are compatible with this starter before mounting. Do not exceed the rated ampacity or interrupting capacity of the device.

Technical Specifications

• Amperage Rating: 200 amps
• Number of Circuits: 32
• Interrupting Capacity: 22k
• Type: Field-convertible combination starter

Standard Information

• Brand: ABB
• Manufacturer Part Number: tlm3220ccu
