Abb THT104 Solid Snap-on Handle Tie 2 Pole Thql

Product Description

The ABB THT104 is a solid snap-on handle tie designed for use with single-pole circuit breakers. The handle tie physically links two adjacent breaker handles so both can be switched on or off together manually. It installs without tools by snapping directly onto compatible breaker handles. The THT104 does not provide internal common trip functionality — that is an inherent feature of true multi-pole breakers. This device is strictly a manual on-off coupling mechanism between two single-pole devices, making it a practical solution for simultaneous switching in panel applications.

The THT104 is used in residential and light commercial electrical panels where two single-pole breakers need to be ganged for manual simultaneous operation. Typical applications include 240-volt circuits built from two single-pole breakers and branch circuits requiring a common manual disconnect. Compatible breaker families for this handle tie include TQB, TQC, and TQL single-pole breakers. Electricians install this tie during new panel construction or as a retrofit on existing breaker installations.

Key Features

• Solid snap-on design installs without tools onto compatible breaker handles
• Links two single-pole breakers for simultaneous manual on-off switching
• Compatible with TQB, TQC, and TQL single-pole breaker series
• Does not replace internal common trip — provides manual coupling only
• Designed for use with THQL-style breaker configurations

Compatibility

Designed for use with TQB, TQC, and TQL single-pole circuit breakers. Provides manual handle ganging for 2-pole configurations using these single-pole devices.

Installation Notes

Installation should be performed by a licensed electrician in accordance with NEC requirements. De-energize the panel and turn off the main breaker before working inside the enclosure. The handle tie snaps onto the breaker handles without fasteners — confirm full seating before restoring power. Note that this tie provides manual on-off coupling only and does not create an internal common trip between the two breakers.

Technical Specifications

• Configuration: 2 Pole
• Attachment Method: Solid Snap-On
• UPC: 783164013085

Standard Information

• Brand: ABB
• Manufacturer Part Number: THT104
