Abb thqp235 thqp 2 pole miniature circuit breaker 35a

Product Description

The ABB THQP235 is a 35A two-pole miniature circuit breaker designed to maximize panel density with its slim half-inch per pole profile. It provides thermal-magnetic trip functions for residential or commercial electrical systems. It mounts into standard GE Q-Line and PowerMark Gold load centers using a secure plug-on connection.

• 35-amp breaker
• Slim half-inch per pole profile
• Rated for 10kAIC at 120/240V

Product Highlights

This breaker offers a compact solution for modern electrical systems, ensuring safety and efficient use of space.

Product Information

Standard Information

• Brand: ABB
• Manufacturer Part Number: THQP235

Technical Specifications

• Brand: ABB / General Electric
• Series: THQP
• Part Number: THQP235
• Amperage: 35A
• Voltage: 120/240VAC
• Poles: 2
• Phase: 1
• AIC Rating: 10kA @ 120/240VAC
• Mounting Style: Plug-On
• Terminal Type: Box Lugs
• For Use With: GE Q-Line Load Centers, PowerMark Gold Load Centers
• Trip Technology: Thermal Magnetic
• Trip Function Code: LI
• Trip Function: Long-Time, Instantaneous
• Trip Adjustability: Fixed
• Wire Gauge: 8-4 AWG (Cu), 8-4 AWG (Al)
• Max Wire: 4 AWG
• Min Wire: 8 AWG
• Available Options: Padlock Attachment
• Standards: CSA C22.2 No. 5, HACR, UL 489
• Approval: CSA, UL
• Temp Rating: -25C to 70C
• Construction Features: HACR Rated, Common Trip, Reverse Feed, Quick-Make/Quick-Break
• Actuator Type: Pivot/Toggle Handle
• Connection Type: Load Lug
• Frequency Rating: 50/60 Hz
• Interrupt Rating: 10 kA
• Material: Plastic
• Trip Type: Thermal Magnetic
• Type: Type THQP Compact
• Wire Size: 8 to 4 AWG
