Abb THQL32030 Circuit Breaker 3 Pole 30 Amp 240V

Product Description

The ABB THQL32030 is a 3-pole, thermal-magnetic circuit breaker rated at 30 amps and 240 volts, built for residential and commercial electrical distribution systems. Part of the Q Line series, it is one inch wide per pole, making it a compact fit for load centers and lighting panels. The breaker carries an interrupting rating of 10 kAIC. Quick-make and Quick-break mechanisms provide consistent overcurrent response, and a visual trip indicator allows technicians to identify a tripped breaker at a glance. Licensed electricians install this device during panel builds, service upgrades, and branch circuit replacements.

The THQL32030 is suited for residential load centers and commercial lighting panels where a compact 3-pole breaker is required. Its thermal-magnetic design responds to both sustained overload conditions and short-circuit faults, protecting downstream wiring and equipment. The breaker can be ordered with auxiliary contact and shunt trip accessories for control and monitoring applications. It is also available for use in HID lighting applications, making it a flexible choice across multiple project types.

Key Features

• 3-pole configuration rated at 30 amps and 240 volts
• 10 kAIC interrupting rating for overcurrent fault protection
• One inch per pole width for compact panel installations
• Quick-make and Quick-break mechanism for reliable overcurrent response
• Common trip bar ensures simultaneous pole interruption on fault
• Easy-to-spot trip indication for fast identification during service
• Compatible with auxiliary contact and shunt trip accessories

Compatibility

Designed as an OEM-style replacement and standard fit for Q Line load centers and lighting panels accepting one-inch-per-pole thermal-magnetic circuit breakers in residential and commercial applications.

Installation Notes

Installation must be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and applicable local codes. Always de-energize the panel and verify absence of voltage before handling breakers or bus connections. Confirm the panel is rated for Q Line devices before installing. Do not exceed the breaker ampere or voltage ratings for the intended circuit.

Technical Specifications

• Number of Poles: 3
• Ampere Rating: 30 amps
• Voltage Rating: 240 volts
• Interrupting Rating: 10 kAIC
• Trip Type: Thermal-Magnetic
• Width per Pole: 1 inch
• Application: Residential and Commercial
• UPC: 783164013023

Standard Information

• Brand: ABB
• Manufacturer Part Number: THQL32030
