Abb THQL1120GF thql 1 pole 120v 10k ic20 amp gfci THQL1120GFT

Product Description

The ABB THQL1120GF is a compact, thermal-magnetic Q Line circuit breaker, one-inch wide per pole, designed for residential and commercial applications. This plug-in device provides ground-fault protection for 120V circuits, meeting NEC requirements for wet or damp locations. It features Quick-make/Quick-break mechanisms and a common trip bar, ensuring circuit protection and reliability. The breaker is compatible with GE Q-Line, PowerMark Gold, and ABB ReliaHome load centers.

• Q line circuit breakers are one-inch wide per pole, compact, thermal-magnetic devices designed for residential and commercial applications.
• The QL breakers are plug-in versions of the Q Line used for connection to load centers and lighting panels.
• All Q Line circuit breakers feature Quick-make / Quick-break mechanisms, common trip bars, and easy to spot trip indication to ensure safety and reliability.

Product Highlights

Provides ground-fault protection for residential and commercial 120V applications.

Product Information

Standard Information

• Brand: ABB
• Manufacturer Part Number: THQL1120GF

Technical Specifications

• Part Number: THQL1120GF
• SKU: THQL1120GF ABB
• Manufacturer: ABB
• Brand: ABB
• Type: Circuit Breakers
• Application: CB3 Ground Fault Circuit Interrupters (GFCI)
• Sub-Brand: Q Line CB3
• Series: THQL
• Amperage: 20A
• Voltage: 120VAC
• Poles: 1
• Phase: 1
• Interrupting Capacity: 10kA @ 120VAC
• Special Classification: GFCI
• Mounting Style: Plug-On
• Terminal Type: Box Lugs
• For Use With: GE Q-Line Load Centers, GE PowerMark Gold Load Centers, ABB ReliaHome Load Centers
• Trip Technology: Thermal Magnetic
• Trip Function Code: LIG
• Trip Function: Long-Time, Instantaneous, Ground Fault
• Trip Adjustability: Fixed
• Wire Gauge: 14-8 AWG (Cu), 12-8 AWG (Al)
• Max Wire Gauge: 8 AWG
• Min Wire Gauge: 14 AWG (Cu), 12 AWG (Al)
• Available Options: Padlock Attachment
• Accessories: THQL1120GF-R
• Standards: HACR, NEMA AB 1, UL 489, UL 943
• Approval: CSA, UL
• Temperature Rating: 60C to 75C
• Construction Features: HACR Rated, SWD Rated, Quick-Make/Quick-Break, Visual Trip Indicator
• Frame: Q-Line
• Trip Type: Non-Interchangeable
• Category: Power Distribution
• Subcategory: Power Distribution > Circuit Breakers > Circuit Breakers - Plug-On > Residential Ground Fault Circuit Breakers
• Family/Style: Q Line
