Abb thql1115pdf 15A dual function miniature circuit breaker

Product Description

The ABB THQL1115PDF delivers comprehensive arc-fault and ground-fault protection in a 15A, 1-pole configuration. Rated for 10kAIC at 120V, this dual function breaker helps meet modern NEC safety requirements for residential circuits. Designed for plug-on neutral load centers, it installs into ABB ReliaHome, GE PowerMark PRO, and compatible PowerMark Gold panels.

• Comprehensive arc-fault and ground-fault protection
• 15A, 1-pole configuration
• Rated for 10kAIC at 120V
• Meets modern NEC safety requirements for residential circuits

Product Highlights

This breaker features a visual LED trip indicator and integrated self-test. The plug-on neutral design eliminates the pigtail connection.

Product Information

Standard Information

• Brand: ABB
• Manufacturer Part Number: THQL1115PDF

Technical Specifications

• Brand: ABB
• Series: THQL
• Amperage: 15A
• Voltage: 120VAC
• Poles: 1
• Phase: 1
• AIC Rating: 10kA @ 120VAC
• Special Classification: Dual Function (AFCI/GFCI)
• Mounting Style: Plug-On
• Terminal Type: Box Lugs
• For Use With: ABB ReliaHome Load Centers, GE PowerMark PRO Load Centers, GE PowerMark Gold Load Centers (Plug-on Neutral compatible only)
• Trip Technology: Thermal Magnetic
• Trip Function Code: LIG
• Trip Function: Long-Time, Instantaneous, Ground Fault
• Trip Adjustability: Fixed
• Wire Gauge: 14-8 AWG (Cu), 12-8 AWG (Al)
• Max Wire: 8 AWG
• Min Wire: 14 AWG (Cu), 12 AWG (Al)
• Available Options: Padlock Attachment
• Accessories: Plug-on Neutral
• Standards: HACR, SWD, UL 1699, UL 489, UL 943
• Approval: UL
• Temp Rating: 40C
• Construction Features: HACR Rated, SWD Rated, Self-Test, Visual Trip Indicator, Quick-Make/Quick-Break
• Amperage Rating: 15 Amp
• Interrupt Rating: 10 kA
• Type: Type THQL
• Frame: THQL
• Connection Type: Plug-On Neutral
• Wire Size: 14-8 AWG Cu / 12-8 AWG Al
• Enclosure Type: Molded Case
• Temperature Rating: 60°C / 75°C
