Abb THP100 Breaker Handle Padlock Adapter

Product Description

The ABB THP100 is a snap-on handle lock designed to accept a padlock on THQL series circuit breakers. It mounts directly to the breaker handle without tools, providing a physical lockout point that prevents unauthorized or accidental operation of the breaker. This type of lockout device is a standard requirement in facilities maintenance, panel service, and OSHA-compliant lockout/tagout programs. The THP100 does not include a padlock — a standard padlock with the appropriate shackle diameter must be sourced separately. Electricians and facilities personnel install this device on load center breakers where locked-off or locked-on positions must be maintained.

The THP100 is intended for single-phase load center applications using THQL breakers. It is commonly installed in residential and light commercial load centers during panel upgrades, tenant buildouts, or facility safety compliance work. The snap-on design allows for fast installation and removal without modifying the breaker or the panel enclosure.

Key Features

• Snap-on installation — attaches directly to THQL breaker handles without tools
• Accepts a standard padlock to secure the breaker in the locked-off or locked-on position
• Supports OSHA lockout/tagout compliance requirements
• Designed specifically for single-phase load center THQL breakers
• Padlock not included — sold separately

Compatibility

Designed for use with THQL series circuit breakers in single-phase load centers.

Installation Notes

Installation should be performed by a licensed electrician in accordance with NFPA 70 (NEC) and applicable lockout/tagout procedures. De-energize the circuit and follow your facility lockout/tagout program before working in the panel. Snap the THP100 onto the THQL breaker handle and verify it is seated securely before applying the padlock. Do not force the device onto breaker handle styles for which it is not rated.

Technical Specifications

• UPC: 783164011418
• Compatible Breaker Series: THQL
• Phase: Single-phase

Standard Information

• Brand: ABB
• Manufacturer Part Number: THP100
