Abb TH3364 Fusible Safety Switch 200A 600V 3P Heavy Duty

Product Description

The ABB TH3364 is a heavy-duty fusible safety switch rated for 200 amps at 600 volts with a 3-pole configuration. It is housed in a NEMA 1 enclosure, making it suitable for general indoor installations in commercial and industrial facilities. The switch provides a reliable means of disconnecting power to electrical equipment and is designed to accept fuses for overcurrent protection. Licensed electricians install this type of switch as a service entrance disconnect, feeder disconnect, or motor circuit disconnect on distribution systems.

The TH3364 is designed for commercial and industrial applications where a robust, code-compliant disconnect is required. Typical installations include manufacturing facilities, processing plants, and commercial buildings where heavy-duty switching capacity is needed. The NEMA 1 enclosure is rated for clean, dry indoor environments. This switch handles the high fault currents and cycling demands found in industrial electrical systems, making it a standard choice for panel feeders and large motor disconnect applications.

Key Features

• 200 amp continuous current rating at 600 volts
• 3-pole configuration for three-phase circuit disconnects
• Fusible design provides integrated overcurrent protection
• Heavy-duty construction rated for commercial and industrial service
• NEMA 1 enclosure for protected indoor installations

Compatibility

Designed as a heavy-duty fusible safety switch for commercial and industrial electrical distribution systems requiring a 200 amp, 600 volt, 3-pole indoor disconnect.

Installation Notes

Installation must be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and all applicable local codes. De-energize and lock out the upstream power source before installing or servicing the switch. Verify fuse class and ampere rating compatibility before inserting fuses. The NEMA 1 enclosure is suitable for indoor dry locations only and must not be installed in wet or outdoor environments.

Technical Specifications

• Amperage Rating: 200 amps
• Voltage Rating: 600 volts
• Poles: 3
• Switch Type: Fusible
• Duty Rating: Heavy Duty
• Enclosure Type: NEMA 1
• UPC: 783164009156

Standard Information

• Brand: ABB
• Manufacturer Part Number: TH3364
