Product Description

The ABB TGN3324 is a general duty non-fusible safety switch, designed for residential and light commercial applications. Rated at 240 VAC and 200 A, it supports 15 hp standard fuse and 50 hp time delay. This 3-pole switch is suitable for use as service equipment when installed according to the national electrical code.

  • General Duty
  • Non-Fusible
  • Safety Switch

Product Highlights

The TGN3324 safety switch is ideal for ensuring safety in residential and light commercial electrical systems.

Product Information

Standard Information

  • Brand: ABB
  • Manufacturer Part Number: TGN3324

Technical Specifications

  • Voltage: 240 VAC
  • Amperage: 200 A
  • Horsepower (Standard Fuse): 15 hp
  • Horsepower (Time Delay): 50 hp
  • Poles: 3
  • Category: General Duty
  • Wires: 3
  • Fusing: No Fuse
  • Enclosure: NEMA 1 (Indoor)
  • Wire Range (Cu/Al): 2-250
  • GSA Compliance: Yes
  • cUL Listed: Yes
  • UL Listed: Yes
  • Height: 29.1
  • Depth: 5.2
  • Width: 13.4
  • Amperage Rating: 200 A
  • Number of Poles: 3
  • Length: 29.88
  • Type: General Duty Non-Fusible
  • Series: TGN
  • Phase: 1/3
  • Frequency Rating: 50/60 Hz
  • Number of Wires: 3
  • Short Circuit Current Rating: 100 kA
  • Actuator Type: Handle
  • Enclosure Type: NEMA 1
  • Mounting Type: Surface
  • Temperature Rating: 60/75 deg C
  • Material: Steel
