Abb tg4324r Fusible Safety Switch 200A 240VAC 3 Pole

Product Description

The ABB tg4324r is a fusible general duty safety switch rated for 200 amps at 240 VAC, designed for residential and light commercial electrical installations. Part of the TG Series, it features a 3-pole, 4-wire configuration with a quick-make, quick-break handle actuator mechanism. The switch carries a 100 kA short circuit current rating and is housed in a NEMA 3R enclosure, making it suitable for outdoor and weatherproof surface-mount applications. A licensed electrician installs this switch as part of a service entrance or disconnect assembly where a reliable, code-compliant shutoff is required.

This safety switch is rated for single-phase, 50/60 Hz service and supports 15 hp loads with standard fuses or time delay fuses. It is intended for residential and light commercial applications where duty conditions are not severe. The steel NEMA 3R enclosure suits installations exposed to rain, sleet, and external ice formation. The 60/75 degrees C conductor rating supports standard copper and aluminum wiring in typical service entrance configurations.

Key Features

• 200A fusible general duty disconnect rated at 240 VAC
• 3-pole, 4-wire configuration for single-phase service
• 100 kA short circuit current rating for service entrance use
• Quick-make, quick-break handle actuator mechanism
• NEMA 3R steel enclosure rated for outdoor surface mounting
• Listed to UL Standard 98 and certified to CSA Standard 22.2 No. 4-04 for enclosed and dead front switches
• Suitable for use as service equipment per National Electrical Code requirements

Compatibility

Designed as an OEM-style general duty fusible safety switch for residential and light commercial service entrance and disconnect applications per the TG Series product line. Meets or exceeds NEMA KS1 standards for enclosed switches type GD.

Installation Notes

Installation must be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and applicable local codes. Verify that all upstream power sources are de-energized and locked out before beginning installation or servicing. The surface-mount NEMA 3R enclosure requires secure fastening to a structural surface capable of supporting the switch. Select fuses appropriate for the connected load in compliance with NEC Article 230 for service equipment applications.

Technical Specifications

• Amperage Rating: 200 A
• Voltage Rating: 240 VAC
• Horsepower Rating: 15 hp Standard Fuse / 15 hp Time Delay
• Phase: 1
• Frequency Rating: 50/60 Hz
• Number of Poles: 3
• Number of Wires: 4
• Short Circuit Current Rating: 100 kA
• Temperature Rating: 60/75 degrees C
• Dimensions (H x W x D): 28.78 inches x 13.4 inches x 5.3 inches
• Enclosure Type: NEMA 3R
• Mounting Type: Surface
• Actuator Type: Handle
• Material: Steel
• Series: TG Series
• Type: Fusible General Duty

Standard Information

• Brand: ABB
• Manufacturer Part Number: tg4324r
