Abb TG3223 Spec-Setter Safety Switch 240 VAC 100 A

Product Description

The ABB TG3223 Spec-Setter™ TG Series fusible general-duty safety switch is designed for residential and light commercial applications. Rated at 240 VAC and 100 A, it accommodates 7-1/2 hp standard fuses or 15 hp time-delay fuses and features 2 poles. This safety switch is UL Listed and suitable for use as service equipment when installed according to the National Electrical Code.

• Fusible safety switch
• Suitable for general duty applications
• Features a quick-make, quick-break mechanism

Product Highlights

Rugged, reliable, and easy to install, this ABB safety switch ensures dependable performance for various applications.

Product Information

Standard Information

• Brand: ABB
• Manufacturer Part Number: TG3223

Technical Specifications

• Voltage: 240 VAC
• Amperage: 100 A
• Fuse Type: 7-1/2 hp Standard Fuse/15 hp Time Delay
• Poles: 2
• Category: General Duty
• Wires: 3
• Fusing: Fusible
• Enclosure: NEMA 1 (Indoor)
• Wire Range (Cu/Al): 10-1/0
• 240 Vac, NEC Std, 1-ph: 7.5
• 240 Vac, Time Delay, 1-ph: 15
• 250 Vdc: 20
• GSA Compliance: Yes
• cUL Listed: Yes
• UL Listed: Yes
• Amperage Rating: 100 A
• Horsepower: 7-1/2 hp Standard Fuse/15 hp Time Delay
• Number of Poles: 2
• Type: Fusible General Duty
• Series: TG Series
• Phase: 1
• Frequency Rating: 50/60 Hz
• Number of Wires: 3
• Short Circuit Current Rating: 100 kA
• Actuator Type: Handle
• Enclosure Type: NEMA 1
• Mounting Type: Surface
• Temperature Rating: 60/75 deg C
• Material: Steel
• UNSPSC: 39122205
• Approval: UL 98, CUL, CSA C22.2
• Neutral Type: Bondable/Groundable/Insulated
• Current Rating: 100 Amp
• Fuse Provision: Fusible
• DC Voltage Rating: 250 Volt
• AC Voltage Rating: 240 Volt
